Wet Pan Mill
Wet Pan Mill is an economical grinding machine for gold ore processing, particularly suitable for small- and medium-scale mining operations. It can grind gold-bearing ore to approximately 100–150 mesh for subsequent mineral recovery.
DESCRIPTION
The Wet Pan Mill is a practical grinding and gold beneficiation machine designed primarily for small- and medium-scale gold processing operations. It is particularly suitable for grinding gold-bearing rock and ore into fine particles for subsequent mineral recovery.
With its simple structure, straightforward operation and relatively low investment requirements, the Wet Pan Mill provides an economical grinding solution for gold processing plants and small-scale mining operations. According to the product catalog, the machine can grind gold ore to approximately 100–150 mesh.
SPECIFICATIONS
The Wet Pan Mill is available in multiple models from 1100B to 1600A to meet different gold ore grinding requirements. All models are designed for a maximum feed size below 25 mm, with motor power ranging from 5.5 to 30 kW. Different roller specifications and machine sizes are available for small- and medium-scale gold processing operations.
| Model | Roller Specification (mm) | Max. Feed Size (mm) | Speed (r/min) | Motor Power (kW) | Weight (t) |
|---|---|---|---|---|---|
| 1600A | 1600×400×200×500±20 | <25 | 10–12 | 30 | 14.5 |
| 1500A | 1500×350×150×460±20 | <25 | 10–12 | 22 | 12.3 |
| 1500B | 1500×300×150×420±20 | <25 | 10–12 | 18.5 | 11.3 |
| 1400A | 1400×350×150×350±20 | <25 | 10–12 | 15 | 8.5 |
| 1400B | 1400×300×150×350±20 | <25 | 10–12 | 15 | 8.5 |
| 1300A | 1300×250×150×350±20 | <25 | 10–12 | 11 | 7.5 |
| 1300B | 1300×200×150×350±20 | <25 | 10–12 | 11 | 7.5 |
| 1200A | 1200×200×80×270±20 | <25 | 12.5 | 7.5 | 5.5 |
| 1200B | 1200×180×80×250±20 | <25 | 12.5 | 7.5 | 5.5 |
| 1100B | 1100×180×80×250±20 | <25 | 12 | 5.5 | 5 |
KEY FEATURES
2. Economical Grinding Solution Suitable for projects requiring relatively simple equipment configuration and lower initial investment.
3. Simple Structure The straightforward mechanical structure makes the machine practical for mineral processing applications.
4. Easy Operation Designed for convenient operation in small- and medium-scale gold processing plants.
5. Suitable for Small-Scale Gold Processing A practical choice for smaller gold beneficiation projects, particularly where a simple grinding solution is required.
Applications
Gold Ore • Gold-Bearing Rock • Small-Scale Gold Processing
The Wet Pan Mill is mainly used for grinding gold-bearing ores and is particularly suitable for small- and medium-scale gold beneficiation operations.
Working Principle
During operation, the grinding wheels rotate and roll over the material inside the grinding pan. The ore is continuously crushed, pressed and ground between the grinding wheels and the pan until the required particle size is achieved. The ground material can then proceed to the subsequent gold recovery process.
